Specifications
PRODUCT PROFILE
-
Main FunctionCellar Reds & Whites
-
Alternate FunctionServe Reds OR Whites
-
No of Zones1
-
Temperature Range Zone 1 (deg)6 - 18
-
Temperature Range Zone 2 (deg)N/A
-
Temperature Range Zone 3 (deg)N/A
-
Door ConstructionTriple Glazed UV treated
-
Installation TypeSlot-in
-
DomesticWarrantySG1
-
Product InstallationBuilt-In or Freestanding
-
Easy Capacity (Bottles)18
-
Max Capacity (Bottles)20
-
HandleRecessed
-
Door TypeGlass Door
-
FinishBorderless Black Glass
DIMENSIONS & WEIGHT
-
Height (mm)820
-
Width (mm)295
-
Depth (mm)561
-
Joinery cut out dimension- minimum h850
-
Joinery cut out dimension- minimum w315
-
Joinery cut out dimension- minimum d554
-
Air space above cabinet (mm)30
-
Air space at sides (mm)10
-
Rear Spacer (mm)30
PERFORMANCE
-
Electricity Consumption (kWh/Day)0.384
-
Ambient Temperature (deg)5-43
-
RefrigerantR600a
CABINET FEATURES
-
LockYes
-
AlarmNone
-
Display PanelLED Digital Display
-
Internal HeaterNo
-
Number of Shelves6
-
Shelving MaterialWood
-
Shelving Type5 Full, 1 Half
-
LightingWhite LED
OTHER
-
HingeRight
-
RangeNameNoir
-
ZonesDenominationSingle-Zone
-
UVTreatedYes
-
CutOffThermostatYes
-
AirFilterNo
-
AdjustableShelvesYes
-
SlidingShelvesTypeStandard glide rails, partial extension
-
ReversibleYes by customer; charges apply for service
-
OppositeHingingPCN/A
-
LightPositionTop
