Auto Test
-
Built-in ELCB
-
Product Description
Description
- Auto Test
- Built-in ELCB
- Line Fault indicator
- NTC Thermal Cut-Out
- Built-in auto flow sensor
- Double Copper Heating Element
- Splash-proof IP25 Standard
- Stepless Electronic Temperature Control
- 5 spray Pattern showerhead
-
Specification
- Application voltage : 230V±10%，Extreme conditions 260V
- Applicable air humidity : 50-98%RH
- Disconnect mode : Double Disconnection
- Strong Connection : Japan JST Connector
- Power Supply Voltage & Frequency (V/Hz) : 230V~,1Ph 50Hz
- Power Comsuption : 3300W
- Rated Current : 14.3A
- Minimum Inlet Pressure : 0.03MPa
- Maximum Inlet Pressure : 0.3MPa
- Max Outlet Water Temperature(°C) : 48℃
- Constant Temperature Performance : ±2℃
- Tank/heating element components Life Time : 6 years
- Minimum Flow Rate : 1.5L/min
- Operating Condition : Open type
- Pump : No
- Applicable Water Pressure : 0.03～0.3Mpa
- Feed Water Temperature : 5～40℃
- Applicable Feed Water : Tap water, TDS≤450mg/L
- Rated presssure : 0 MPa
- Inlet and Outlet pipe joint Dimension : G1/2″
-
Material
- Heating tube material : Copper
- Front Housing Materials(ABS/PP/HIPS) : ABS
- Back Base Materials (ABS/PP/HIPS) : ABS
- The Inlet / Outlet Pipe Materials : PA66+30%GF
- Water Proof Class : IP25
- Protection Class : Class I
-
Dimension
- Product Dimensions（mm） : 200*400*97 mm
- Packing Dimensions（mm） : 660*260*125 mm
- Outer Packing Dimensions（mm）: 675*520*280 mm
- Number of outer packing box : 4
- N.W.（kg） : 1.95
