Specification:
Application voltage
230V±10%，Extreme conditions 260V
Power Supply Voltage & Frequency (V Hz)
230V~,1Ph 50Hz
Maximum Inlet Pressure
0.3MPa
Rated pressure
0 MPa
Applicable Water Pressure
0.03～0.3Mpa
Applicable air humidity
50-98%RH
Power Comsuption
3300W
Max Outlet Water Temperature(°C)
48℃
Minimum Flow Rate
1.5L/min
Feed Water Temperature
5～40℃
Disconnect mode
Double Disconnection
Rated Current
14.3A
Constant Temperature Performance
±2℃
Operating Condition
Open Type
Applicable Feed Water
Tap water, TDS≤450mg/L
Strong Connection
Japan JST Connector
Minimum Inlet Pressure
0.03MPa
Tank heating element components Life Time
