Specifications
Cooktop
3 EA
Net (WxHxD)
690 x 108 x 645 mm
Specifications Detail
Materials/Finishes
Model Type Install
Built- In
Color
Black
Cooktop Frame
4 Metal Frame
Control Method
Touch
Display Type
LED (Red)
Power/Ratings
Power Source
220-240 V ~ 50 / 60 Hz
Total Power (kW)
3.4 kW
Qty of Power Boost
3
Power Level
9 + Boost
Burner - Left Front
180 mm - 1800 / 2800 W
Burner - Left Rear
145 mm - 1400 / 2000 kW
Burner - Right
280 mm - 2400 / 3400 W
Features
Child Safety Lock
Yes
Kitchen Timer
Yes
Pause
Yes
Residual Heat Indicator
Yes
Safety Shutoff
Yes
High Temp. Limit
Yes
Auto Pan Detection
Yes
Sound on/off
Yes
Power On/Off
Yes
Cooktop
Number of Burner
3 EA
Type
Induction
Virtual Flame
No
Smart
WiFi Embedded
Yes
App Connectivity
SmartThings App Support
Yes
Weights/Dimensions
Package (WxHxD)
600 x 48 x 520 mm
Cutout (WxHxD)
560 x 480 mm
Net (WxHxD)
690 x 108 x 645 mm
Weight (Gross)
12.6 kg
Weight (Net)
11.0 kg
