Description
SOUND
-
- Speaker Output - Number of channels
- 3.1.3ch
- Speaker Output - Total
- 480W
-
- Speaker Output - Front
- 45W X 2
- Speaker Output - Center
- 40W
-
- Speaker Output - Top
- 45W x 2
- Speaker Output - Top Center
- 40W
-
- Subwoofer Output - Subwoofer
- 220W (Wireless)
CONNECTIVITY
-
- Optical
- Yes (1)
- HDMI - In / Out
- Yes (1) / Yes(1)
-
- HDR10 / HDR10+
- HDR10
- Dolby Vision
- Yes
-
- USB
- Yes
- Bluetooth Version
- 5.0
-
- Bluetooth Codec - SBC/AAC
- Yes / Yes
- Wi-Fi (2.4G / 5G)
- Yes
-
- Wireless Rear ready
- Yes (1:2)
CONVENIENCE
-
- Remote App - iOS / Android OS - iOS / Android OS
- Yes / Yes
- Smart Phone File Playback
- Yes
-
- Control with your TV Remote - (Vol+/-, Mute)
- Yes / Yes
- Sound Sync - Bluetooth(LG TV) / Optical
- Yes (Optical)
-
- CEC SIMPLINK
- Yes
- HDMI Audio Return Channel (ARC)
- Yes
-
- HDMI Audio Return Channel (e-ARC)
- Yes
MUSIC APPLICATION
-
- Spotify Supported - Spotify Connect
- Yes
- Apple Supported - AirPlay 2
- Yes
AI
-
- Works with the Google Assistant - Controllee
- Yes
- Chromecast
- Yes
-
- Google Multi Zone - One Source → Multi Speaker
- Yes
SOUND EFFECT
-
- AI Sound Pro
- Yes
- Standard
- Yes
-
- Music
- Yes (w/ Meridian)
- Cinema
- yes
-
- Clear Voice
- Yes
- Sports
- Yes
-
- Game
- Yes
- Bass Blast / Bass Blast +
- Yes
-
- Dolby ATMOS
- Yes
- DTS:X
- Yes
-
- IMAX Enhanced
- Yes
AUDIO FOMAT
-
- LPCM
- Yes
- Dolby Atmos
- Yes
-
- Dolby TrueHD
- Yes
- Dolby Digital Plus
- Yes
-
- Dolby Digital
- Yes
- DTS:X
- Yes
-
- DTS-HD Master Audio
- Yes
- DTS-HD High Resolution
- Yes
-
- DTS Digital Surround
- Yes
- AAC / AAC+
- Yes
SOUND CONTROL
-
- User EQ - RCU / App
- Yes / Yes
- Night Time On/Off - RCU / App
- Yes / Yes
-
- Dynamic Rage On/Off - RCU / App
- No / Yes
- Auto Volume Leveler On/Off - RCU / App
- No / Yes
-
- Surround On/Off - RCU / App - RCU / App
- Yes / Yes
- AI Room Calibration - (2 MIC In) - App
- Yes
-
- Soundbar Mode Control (by TV GUI)
- Yes
- TV Sound Mode Share
- Yes
HI-RESOLUTION AUDIO
-
- Sampling - 24bit/192kHz/24bit/96kHz
- No / Yes
- Upbit/upsampling - 24bit/192kHz/24bit/96kHz
- No / YES
FILE FORMAT
-
- FLAC - C4A/USB
- Yes / Yes
- OGG - C4A/USB
- Yes / Yes
-
- WAV - C4A/USB
- Yes / Yes
- MP3 - C4A/USB
- Yes / Yes
-
- AAC - C4A/USB
- Yes / Yes
POWER
-
- Main - Switch Mode Power Supplies
- Yes
- Main -Power Off Consumption
- 0.5W ↓
-
- Main - Power Consumption
- 59W
- Subwoofer - Type (SMPS)
- Yes
-
- Subwoofer - Power Off Consumption
- 0.5W ↓
- Subwoofer - Power Consumption
- 40W
-
- Subwoofer - Wireless Frequency
- 5GHz
ACCESSORIES
-
- Remote Control - Model Name
- RAV21
- Remote Control - Battery(Size)
- AA x 2
-
- Remote Control - Battery Built-in
- Yes
- Others - Wall Mount Bracket
- Yes
-
- Others - HDMI Cable
- Yes
DIMENSION
-
- Main (w/ Foot ) - Size (W x H x D, mm)
- 1000 x 63 x 135
- Matching TV size - 2020 New Model
- 55 ~ 65 inch
-
- Subwoofer - Size (W x H x D, mm)
- 201.7 x 407 x 403
WEIGHT
-
- Main (kg)
- 4.5
- Subwoofer (kg)
- 10
-
- Gross Weight (kg)
- 18.7
