Portability like no other
The stylish and portable imageFORMULA P-215II has convenient USB power and plug-and-scan capabilities to deliver high-resolution outputs in black & white, or colour up to 600dpi on the go.
-
Portable Document Scanner
-
Scan Size: A4
-
Scan Speed: Up to 15 ppm (Simplex) / 30 ipm (Duplex)
Scan
Type
Desktop Sheet-Fed Scanner
Scanning Speed*1
Greyscale
200 dpi: 15 ppm (Simplex) / 30 ipm (Duplex) 300 dpi: 15 ppm (Simplex) / 30 ipm (Duplex)
Colour
200 dpi: 10 ppm (Simplex) / 20 ipm (Duplex) 300 dpi: 6 ppm (Simplex) / 12 ipm (Duplex)
Scanning Element
Contact Image Sensor (CIS)
Light Source
LED
Scanning Side
Simplex / Duplex
Scanning Modes
Black and White, Error Diffusion, Advanced Text Enhancement II, 256-level Greyscale, 24-bit Colour
Scanner Features
Double-Feed Detection, Moiré Reduction, MultiStream
Output Resolution*2
150, 200, 300, 400, 600 dpi
Suggested Daily Volume (SDV)
500 scans a day
Media Handling
Document Size
Plain Paper
Width: 50.8 to 216 mm Length: 70 to 356 mm (Up to 1,000 mm long with Long Document mode)
Business Card
Width: 49 to 55 mm Length: 85 to 91 mm
Card (ISO Standard)
86 x 54 mm
Document Thickness and Weight
Plain Paper
52 to 128 g/m² (0.06 to 0.15 mm)
Business Card
128 to 225 g/m² (0.15 to 0.3 mm)
Card
0.76 mm or smaller (Up to 1.4 mm for embossed cards)
Auto Document Feeder (ADF) Capacity*3
20 sheets
Connectivity & Software
Interface
USB 3.0 / 2.0
Software
ISIS / TWAIN Drivers, CaptureOnTouch Lite, CaptureOnTouch
General
Power Requirements
USB 2.0: 0.5 A (Communication cable only) / 1 A (In combination with power supply USB cable) USB 3.0: 0.9 A / 6 V DC, 0.8 A (With optional AC adapter)
Power Consumption
Scanning (Max.)
USB cable only: 2.5 W (USB 2.0) / 4.5 W (USB 3.0) USB cable and power supply USB cable: 5 W (USB 2.0) / 7 W (USB 3.0)
Sleep Mode
1.5 W
With Power Switched OFF (Max.)
0.1 W
Operating Environment
Temperature
10 to 32.5°C
Humidity
25 to 80% RH
Dimensions (W x D x H)
When Trays Are Closed
285 x 95 x 40 mm
When Trays Are Opened
285 x 257 x 174 mm
Weight (Approx.)
1 kg
Consumables & Accessories
Options / Consumables
Feed Roller, Separation Pad, USB Cable, AC Adapter, Carrying Case
-
Based on A4 portrait document size. When using USB 3.0 / 2.0 bus power in combination with the power supply USB cable.
-
Primary scan lines x secondary scan lines.
-
Paper weight: 64 g/m².
