Basic Specs
ADF (AUTOMATIC DOCUMENT FEEDER)
Max. 20 pages
SPEED DIAL
200 stations
Fax
COMPATIBILITY
ITU-T Super Group 3
MODEM SPEED
33,600 bps (with automatic fallback)
SCANNING WIDTH
Max. 208 mm
PRINTING WIDTH
Max. 208 mm
GREYSCALE
8-bit/256 levels
HORIZONTAL RESOLUTION
8 dot/mm
STANDARD
3.85 line/mm
FINE
7.7 line/mm
7.7 line/mm
SUPERFINE
15.4 line/mm
ONE-TOUCH DIAL
22 stations
GROUPS
Max. 8
BROADCASTING
272 locations
AUTOMATIC REDIAL
3 times at 5-minute intervals
MEMORY TRANSMISSION
Max. 400 pages
OUT OF PAPER RECEPTION
Max. 400 pages
Document Size
WIDTH
147.3 mm to 215.9 mm
LENGTH
147.3 mm to 355.6 mm
Display, connectivity & memory
LCD (LIQUID CRYSTAL DISPLAY)
16 characters × 2 lines
MEMORY CAPACITY
16 MB
USB
Hi-Speed USB 2.0. Use a Type A/B USB 2.0 cable no longer than 2 meters.
Copy
COLOUR/MONOCHROME
Monochrome
COPY WIDTH
Max. 204 mm
MULTIPLE COPIES
Stacks up to 99 pages
REDUCE/ENLARGE
25% to 400%
FIRST COPY OUT TIME
Less than 12 seconds
Printer
RESOLUTION
2,400 dpi × 600 dpi, 600 dpi × 600 dpi
PRINT SPEED
Max. 20 pages/minute (A4 size)
FIRST PRINT OUT TIME
Less than 10 seconds
PRINT METHOD
Electrophotographic laser printer
COPY RESOLUTION
Max. 300 dpi × 600 dpi
Print Media
PAPER INPUT - PAPER TRAY - PAPER TYPE
Plain, thin or recycled paper
PAPER INPUT - PAPER TRAY - PAPER SIZE
Letter, A4, B5 (ISO/JIS), A5, A5 (Long Edge), B6 (ISO), A6, Executive (legal or folio for Asia)
PAPER INPUT - PAPER TRAY - PAPER WEIGHT
60 gsm to 105 gsm
PAPER INPUT - PAPER TRAY - MAXIMUM PAPER TRAY CAPACITY
Up to 250 sheets of 80 gsm plain paper
PAPER INPUT - MANUAL FEED SLOT - PAPER TYPE
Envelope, labels, thin paper, thick paper, recycled paper, bond paper or plain paper
PAPER INPUT - MANUAL FEED SLOT - PAPER SIZE
Width: 76.2 mm to 216 mm Length: 116 mm to 406.4 mm
PAPER INPUT - MANUAL FEED SLOT - PAPER WEIGHT
60 gsm to 163 gsm
PAPER INPUT - MANUAL FEED SLOT - MAXIMUM PAPER TRAY CAPACITY
One sheet at a time, 80 gsm plain paper
PAPER OUTPUT - FACE-DOWN OUTPUT TRAY
Max. 100 sheets of 80 gsm plain paper
PAPER OUTPUT - FACE-DOWN OUTPUT TRAY
One sheet (face-up print delivery to the face-up output tray)
Operation
POWER SOURCE
220 - 240 V AC 50/60Hz
POWER CONSUMPTION - PEAK
Approx. 1,080 W at 25°C
POWER CONSUMPTION - COPYING
Approx. 420 W at 25°C
POWER CONSUMPTION - READY
Approx. 55 W at 25°C
POWER CONSUMPTION - DEEP SLEEP
Approx. 1.5 W
WEIGHT
9 kg
NOISE LEVEL - SOUND POWER - OPERATING (PRINTING)
L wa d = 6.18 dB (A)
NOISE LEVEL - SOUND POWER - STANDBY
L wa d = 4.25 dB (A)
NOISE LEVEL - SOUND PRESSURE - OPERATING (PRINTING)
L pa m = 53 dB (A)
NOISE LEVEL - SOUND PRESSURE - STANDBY
L pa m = 30 dB (A)
TEMPERATURE - OPERATING
10°C to 32.5°C
TEMPERATURE - STORAGE
0°C to 40°C
HUMIDITY - OPERATING
20% to 80% (without condensation)
HUMIDITY - STORAGE
10% to 90% (without condensation)
