Basic Specs
DOCUMENT SIZE - SINGLE PAPER - WIDTH
50.8 mm to 215.9 mm
DOCUMENT SIZE - SINGLE PAPER - LENGTH
86.4 mm to 1,828 mm
COLOUR / BLACK
Yes / Yes
DUPLEX SCAN
Yes
COLOR DEPTH - INPUT
48-bit colour processing
COLOR DEPTH - OUTPUT
24-bit colour processing
RESOLUTION - OPTICAL
Max. 600 dpi × 600 dpi
RESOLUTION - INTERPOLATED
Max. 1,200 dpi × 1,200 dpi
GRAYSCALE
256 levels
PRODUCT DIMENSIONS (WIDTH X DEPTH X HEIGHT)
319 mm x 63.1 mm x 45.4 mm
WARRANTY
1 Year Carry in Warranty
General
MEMORY CAPACITY
512 MB
WEIGHT
0.691 kg
Operation
POWER SOURCE
Lithium battery USB bus-power
POWER CONSUMPTION - SCANNING
USB3.0 mode 3.6W Wi-Fi mode 4.4W
POWER CONSUMPTION - READY
2.2W @Wi-Fi mode 1.5W @PC mode
POWER CONSUMPTION - POWER OFF
0.11W
TEMPERATURE - OPERATING
5 to 35℃
HUMIDITY - OPERATING
20 to 80%
HUMIDITY - STORAGE
10 to 90%
Compliance
TWAIN COMPLIANT - WINDOWS®
Windows® 7 SP1 / Windows® 8.1 / Windows® 10/ Windows Server® 2012 / Windows Server® 2012 R2 / Windows Server® 2016 / Windows Server®2019
TWAIN COMPLIANT - MAC OS
macOS v10.12.x/10.13.x/10.14.x
Interface
USB
Micro USB3.0
WIRELESS LAN
IEEE802.11 b/g/n
Network
WIRELESS NETWORK SECURITY
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES)
SETUP SUPPORT UTILITY
WPS
