Basic Specs
SCANNING SPEED
40 ppm
DOCUMENT SIZE - MULTIPLE PAPERS - WIDTH
50.8 mm to 215.9 mm
DOCUMENT SIZE - MULTIPLE PAPERS - LENGTH
50.8 mm to 355.6 mm
DOCUMENT SIZE - SINGLE PAPER - WIDTH
50.8 mm to 215.9 mm
COLOUR / BLACK
Yes / Yes
DUPLEX SCAN
Yes
COLOR DEPTH - INPUT
48-bit colour processing
COLOR DEPTH - OUTPUT
24-bit colour processing
RESOLUTION - OPTICAL
Up to 600 dpi × 600 dpi
RESOLUTION - INTERPOLATED
Up to 1,200 dpi × 1,200 dpi
SCANNING WIDTH
Up to 215.9 mm
GRAYSCALE
256 levels
PRODUCT DIMENSIONS (WIDTH X DEPTH X HEIGHT)
299.5 mm x 190.5 mm x 215.9 mm
WARRANTY
1 Year Carry in Warranty
General
MEMORY CAPACITY
512 MB
ADF (AUTOMATIC DOCUMENT FEEDER)
Up to 80 sheets (Paper: 20 lb (80 g/m²) A4/Letter size)
WEIGHT
2.75 kg
Display
TOUCHSCREEN LCD (LIQUID CRYSTAL DISPLAY)
4.3 in. (109.2 mm) TFT colour LCD screen
Operation
POWER SOURCE
AC: 100-240 V, 50/60 Hz
POWER CONSUMPTION - SCANNING
Approx. 26W
POWER CONSUMPTION - READY
Approx.8.6W
POWER CONSUMPTION - POWER SAVING / DEEP SLEEP
Approx. 1.7W
POWER CONSUMPTION - POWER OFF
Approx. 0.1W
TEMPERATURE - OPERATING
5°C to 35°C
HUMIDITY - OPERATING
20% to 80%
HUMIDITY - STORAGE
10% to 90%
Compliance
TWAIN COMPLIANT - WINDOWS®
Windows Server 2012 / Windows Server 2012 R2 / Windows Server 2016 / Windows Server 2019
TWAIN COMPLIANT - MAC OS
macOS v10.14.x / 10.15.x / 11.0.x / 11.1.x
WIA COMPLIANT - WINDOWS®
Windows 7 (SP1) / Windows 8.1 / Windows 10
ICA COMPLIANT - MAC OS
macOS v10.14.x / 10.15.x / 11.0.x / 11.1.x
ISISTM COMPLIANT - WINDOWS®
Windows 7 (SP1) / Windows 8.1 / Windows 10
Interface
USB
USB 3.0
LAN
10Base-T/100Base-TX
WIRELESS LAN
2.4GHz Infrastructure Mode : IEEE 802.11b/g/n Wi-Fi Direct : 802.11g/n
Network
WIRELESS NETWORK SECURITY
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES), WPA3
SETUP SUPPORT UTILITY
WPS WLAN Assistant
