General Specifications
Power supply100 - 240V AC, ~ 50/60Hz
Networked standby power< 2.0 W
Operating temperature0°C - 45 °C
Audio Specifications
Total speaker power output (Max @THD 1%)590W
Soundbar output power (Max @THD 1%)290W
Subwoofer output power (Max. @THD 1%)300 W
Soundbar transducer4x (46x90)mm racetrack drivers, 3x 0.75" (20mm) tweeters
Subwoofer transducer10” (260mm)
Frequency response35Hz - 20kHz (-6dB)
Audio inputs1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)
Dimensions
Soundbar dimensions (W x H x D)1017 x 56 x 103.5 mm / 40’’ x 2.2’’ x 4’’
Subwoofer dimensions (W x H x D)305 x 440.4 x 305 mm / 12" x 17.3" x 12"
Soundbar weight2.8kg/ 6.2 lbs
Subwoofer weight10 kg / 22 lbs
Packaging dimensions (W x H x D)1105 x 370 x 475 mm/ 43.5" x 14.6" x 18.7"
Packaging Weight16.2 kg / 35.6 lbs
Control and Connection Specifications
USB portType A
USB rating5V DC, 0.5A
Supporting file formatMP3
MP3 codecMPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
MP3 sampling rate16 - 48 kHz
MP3 bitrate80 - 320 kpbs
Bluetooth version5.0
Bluetooth profileA2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range2400 MHz – 2483.5 MHz
Bluetooth transmitter power<15 dBm (EIRP)
Wi-Fi networkIEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range2412 - 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power< 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range5.15 - 5.35GHz, 5.470-5.725GHz, 5.725 - 5.825GHz
5G Wi-Fi transmitter power5.15-5.25GHz <23dBm, 5.25-5.35GHz & 5.47-5.725GHz <20dBm, 5.725-5.825GHz <14dBm (EIRP)
2.4G wireless transmitter frequency range2406 - 2474MH
2.4G wireless transmitter power＜10dBm (EIRP）
